Oct 29, 2013 | 01:01 AM

#11

dbaldwin

Thread Starter

Monte Of The Month -- January 2014

Joined: Aug 2013

Posts: 1,871

From: Washington

While working on this I realized I always over due my insulating

How to wire a parralel quick connect circuit write up poll-forumrunner_20131028_230116.jpg

their for my wiring harness could be misconstrued as a bomb. Haha.

Oct 29, 2013 | 09:16 AM

#12

Hiroska

Joined: Aug 2012

Posts: 1,062

From: Saint Louis, MO

Looks like u made a mini bomb.

Oct 29, 2013 | 09:22 AM

#13

dbaldwin

Thread Starter

Monte Of The Month -- January 2014

Joined: Aug 2013

Posts: 1,871

From: Washington

Quote:

Originally Posted by Hiroska

Looks like u made a mini bomb.

This is what it looked like without insulation

How to wire a parralel quick connect circuit write up poll-forumrunner_20131029_072154.jpg

Oct 29, 2013 | 09:51 AM

#14

Hiroska

Joined: Aug 2012

Posts: 1,062

From: Saint Louis, MO

So i didnt read the entire thread, but your building a series circut for things such as led lighting?Or stuff like that in general?

Oct 29, 2013 | 09:54 AM

#15

dbaldwin

Thread Starter

Monte Of The Month -- January 2014

Joined: Aug 2013

Posts: 1,871

From: Washington

Quote:

Originally Posted by Hiroska

So i didnt read the entire thread, but your building a series circut for things such as led lighting?Or stuff like that in general?

Just a series curcuit that will provide three 7-10 amp circuits for powering any device you want. My use will be LED's but it will be something you can plug and play into.

Oct 29, 2013 | 10:12 PM

#16

dbaldwin

Thread Starter

Monte Of The Month -- January 2014

Joined: Aug 2013

Posts: 1,871

From: Washington

Had to re insulate my splitter due to size but here's a visual sneak peek

How to wire a parralel quick connect circuit write up poll-forumrunner_20131029_201150.jpg
