6th Gen ('00-'05): Suspension misalignment after strut change
#12
Soo...
I got camber adjustment bolts but winter came here and project stalled.
Last days were a little warmer, so I installed camber bolts.
I will be grateful if anyone post factory suspension alignment parameters/degrees in order to compare it with local alignment shop.
I will keep posting the results :-)
Thanks,
Ivo
I got camber adjustment bolts but winter came here and project stalled.
Last days were a little warmer, so I installed camber bolts.
I will be grateful if anyone post factory suspension alignment parameters/degrees in order to compare it with local alignment shop.
I will keep posting the results :-)
Thanks,
Ivo
#13
Here you go Rack:
WHEEL ALIGNMENT
CHEVROLET MONTE CARLO
Year Model Unnamed Caster Camber Toe-in (in.)
Range (+/- Deg.) Preferred Settings (Deg.) Range (+/- Deg.) Preferred Settings (Deg.)
2004 Monte Carlo F 0.50 +1.80 +0.50 +0.70 0 +/- 0.20
R +0.50 -0.15 0.10 +/- 0.10
2004 CHEVROLET MONTE CARLO SERVICE MANUAL
SEARCH
Suspension Wheel Alignment Specifications
Wheel Alignment Specifications (Front)
Document Preview
Operation
Service Allowable
Service Preferred
Camber – Impala
0.28 to 1.28 Degrees
0.78 Degrees
Camber – Monte Carlo
0.35 to 1.35 Degrees
0.85 Degrees
Caster
2.70 to 3.70 Degrees
Not Adjustable
Steering Angle
3.50 to +3.50 Degrees
0 Degrees
Toe – Total
0.10 to +0.30 D...
WHEEL ALIGNMENT
CHEVROLET MONTE CARLO
Year Model Unnamed Caster Camber Toe-in (in.)
Range (+/- Deg.) Preferred Settings (Deg.) Range (+/- Deg.) Preferred Settings (Deg.)
2004 Monte Carlo F 0.50 +1.80 +0.50 +0.70 0 +/- 0.20
R +0.50 -0.15 0.10 +/- 0.10
2004 CHEVROLET MONTE CARLO SERVICE MANUAL
SEARCH
Suspension Wheel Alignment Specifications
Wheel Alignment Specifications (Front)
Document Preview
Operation
Service Allowable
Service Preferred
Camber – Impala
0.28 to 1.28 Degrees
0.78 Degrees
Camber – Monte Carlo
0.35 to 1.35 Degrees
0.85 Degrees
Caster
2.70 to 3.70 Degrees
Not Adjustable
Steering Angle
3.50 to +3.50 Degrees
0 Degrees
Toe – Total
0.10 to +0.30 D...
Last edited by plumbob; 02-10-2016 at 02:55 PM.
